Soundcraft Ui16 Remote Controlled Rack Mount Digital Mixer

Control Your Mixes Anywhere with the Soundcraft Ui16 Remote Controlled Rack Mount Digital Mixer

The Ui Series mixers feature cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices, and can use up to 10 control devices simultaneously. In addition, the Ui12 and Ui16 each feature built-in HARMAN signal processing from dbx, DigiTech and Lexicon, including dbx AFS2, DigiTech Amp Modeling, and more. Both models feature fully recallable and remote-controlled mic gain and phantom power, along with 4-band parametric EQ, high-pass filter, compressor, de-esser and noise gate on input channels.

Both mixers offer 31-band graphic EQ, noise gate and compressor on all outputs, plus real-time frequency analyzer (RTA) on inputs and outputs. Built in are three dedicated Lexicon FX busses: Reverb, Delay and Chorus. In addition, mixer controls include Subgroups, Mute groups and View groups, among others. The Ui Series mixers feature full Show/Snapshot recallability with channel recall safes. while security lockout features allow customization of device access to only specific functions and mixes if needed. Both mixers also offer independent network interfaces on board for simultaneous control by Wi-Fi and Ethernet, plus a floor-ready rugged chassis for live applications.

The Soundcraft Ui16 boasts eight XLR combo mic/line inputs, four XLR mic inputs, two channels of Hi- Z/instrument inputs, as well as a stereo RCA line input. A 2-channel USB media player is included, along with four balanced XLR Aux outputs, two quarter-inch headphone outputs with level control, plus balanced stereo XLR and quarter-inch main outputs. Two-channel USB audio playback is compatible with MP3, WAV and AIFF formats, and 2-channel USB Record direct-to-memory devices functionality is possible as well. The Ui16 also has an HDMI display connection output.

• Tablet/PC/Smartphone Controlled Digital Mixer
• Integrated Wi-Fi
• Cross-Platform Compatibility With iOS, Android, Windows, Mac Os, And Linux Devices
• Use Up To 10 Control Devices (Tablets, Phones, PSs) Simultaneously
• Legendary Harman Signal Processing From DBX, Digitech, And Lexicon
• Fully Recallable And Remote-Controlled Mic Preamps
• 4-Band Parametric EQ, High-Pass Filter, Compressor, De-Esser And Noise Gate On Input Channels
• 31-Band Graphic EQ, Noise Gate And Compressor On All Outputs
• Real-Time Frequency analyzer (RTA) On Inputs And Outputs
• 3 Dedicated Lexicon FX Effects Processors: Reverb, Delay And Chorus
• Subgroups, Mute Groups, View Groups, And More Mixer Controls
• Show/Snapshot Recall With Channel Safes And Security Lockout

SPECIFICATIONS

• Frequency Response: 20Hz-20kHz +/- 0.25 dB
• THD: -20dBFS @ 1kHz <0.006%
• Input Gain: Mic/Line Gain -40dB to +50dB (0.1dB steps, Step accuracy depends on size of fader in GUI)
• EQ Outputs: 32 band GEQ, 20Hz – 20KHz +-15dB
• dbx AFS on all outputs: 12 parametric EQ’s (6 fixed, 6 floating)
• Latency: Mic in – ADC -DSP -DAC – Line output 1.8ms

Noise

• Residual Noise: -96dBu
• Mic Input E.I.N.22Hz-22kHz unweighted: -109dB EIN
• Mix Noise masters at unity: -90dBu
• 1 input to Mix at Unity gain: -86dBu
• Cross Talk (@1KHZ)
• Channel ON attenuation: 120dB
• Channel Fader Attenuation: 120dB
• Mic-Mic: -103dB@ 1kHz, -93dB@ 10kHz
• Line-Line: -103dB@ 1kHz, -93dB@ 10kHz

Gate

• Threshold -inf to +6dB
• Auto Attack
• Auto Release

Compressor

• Threshold: -90dB +6dB
• Ratio: 1:1 – 50:1
• Attack: 1ms – 400ms
• Release: 10ms – 2000ms
• Makeup Gain: -24dB – +48dB

Eq Channel

• 4 band parametriq EQ
• Each Band Freq 20Hz to 22kHz
• Q: .05 – 15
• Gain: -20dB to +20dB
• HPF: 20Hz to 1kHz

De-Esser

• Threshold: -90dB to 6dB
• Ratio infinity: to 1:1
• Frequency: 2kHz to 15kHz
• Compressor Outputs
• Threshold: -90dB +6dB
• Ratio: 1:1 – 50:1
• Attack: 1ms – 400ms
• Release: 10ms – 2000ms
• Makeup Gain: -24dB – +48dB=

Input And Output Levels

• Mic Input: +20dBu max
• Line input: +20dBu max
• Mix output: +23dBu max
• Headphone outputs: 500mW 1 output used (@120 Ohms), 380mw both outputs used

Input And Output Impedances

• Mic input: 10k Ohms
• Line Input: 10k Ohms
• Hi-Z Input: 250k Ohms
• Outputs: All At 100 Ohms

USB

• Max Current: 500mA
• Max Current available to all ports: 900mA
• Power
• Consumption (typical): 25W
• AC input voltage range: 88-265VAC auto sensing
• AC frequency: 47-63Hz

Operating Conditions

• Temperature range: 5C – 45C
• Humidity: 0%-90%
• Storage Temperature: -20C to 60C

Manufacturer:Soundcraft
Model:5056219
SKU:I350806-7-WHXE
