Zoom L-12 LiveTrak Live Mixer/Recorder

Perfect for Stage or Studio – The Zoom L-12 LiveTrak Live Mixer/Recorder

With the LiveTrak L-12, you can finally mix, record, and monitor with a single piece of gear. LiveTrak is the only digital console that lets you mix your live performance and record up to 12 discrete channels to an SD card, all while providing five powered and savable custom headphone mixes.

• Live digital mixer that records up to 12 discrete channels, plus a stereo mix.
• Perfect for live sets, rehearsals, and podcasting
• Records directly to an SD card, so you can overdub, mix, and bounce your finished track or transfer your discrete tracks to your favorite DAW for mixing
• 9 Scene Slots for saving mixes
• 5 Sub mixes with headphone outs for recording sessions, rehearsals, and live monitors
• Bundled with Ableton Live 9 Lite software

SPECIFICATIONS

Inputs – Mono (Mic/Line)

• Type XLR/TRS combo jacks
• (XLR: 2 HOT, TRS: TIP HOT)
• Input gain: PAD OFF: +16 – +60 dB; PAD ON: 10 +34 dB; Hi-Z ON: +6 – +50 dB
• Input impedance: XLR: 3 k; TRS: 10k/1 M (when Hi-Z ON)
• Maximum input level: PAD OFF: 0 dBu (at 0 dBFS); PAD ON: +26 dBu (at dBFS)
• Phantom Power: +48 V

Inputs – Stereo (Line)

• Type: TRS phone/RCA pin (unbalanced) jacks
• Maximum input level: +10 dBu

Outputs – Master Out

• Type: XLR jacks (balanced)
• Maximum output level: +14.5 dBu
• Output impedance: 100

Outputs – Monitor Out A (TRS)

• Type: TRS phone jacks (balanced)
• Maximum output Level: +14.5 dBu
• Output impedance: 100

Outputs – Monitor Out A-E (Phones)

• Type: Standard Stereo phone jacks
• Maximum output level: 42 mW + 42 mW at 60
• Output impedance: 100

Buses

• MASTER: 1
• MONITOR: 5
• SEND EFX: 1

Channel Strip

• COMP
• LOW CUT: 75 Hz, 12 dB/OCT
• EQ: HIGH: 100 kHz, 15 dB, shelving; MID: 100 Hz-8 kHz, 15 dB, peaking; LOW: 100 Hz, 15 dB, shelving

Line Meters

• 12 segments

Send Effects

• Hall 1 & 2 (reverb)
• Room 1 & 2(reverb)
• Plate (reverb)
• Church (reverb)
• DrumAmb (reverb)
• GateRev (reverb)
• Spring (reverb)
• Delay (delay)
• Analog (delay)
• P-P Dly (delay)
• Vocal 1-4 (delay + reverb)

Recorder

• Maximum simultaneous recording tracks:14 at 44.1/48 kHz (12 channel + stereo mix); 12 at 96 kHz
• Maximum simultaneous playback tracks: 12
• Recording Format: WAV 44.1/48/96 kHz, 16/24-bit, mono/stereo WAV format
• Recording Media: 16 MB-2 GB SD cards, 4 GB-32 GB SDHC cards, 64 GB-512 GB SDXC cards

Audio Interface

• 44.1/48 kHz: Recording: 14 channels; Playback: 4 channels
• Bit Depth: 24-bit
• Interface: USB 2.0

Card Reader

• Class: Mass Storage; USB 2.0 High Speed

USB Host

• USB 2.0 High Speed

Sampling Rate

• 44.1/48/96 kHz

Frequency Characteristics

• Frequency characteristics (44.1 kHz): -1.0 dB: 20 Hz – 20 kHz
• Frequency characteristics: (96 kHz): -3.0 dB: 20 Hz – 40 kHz

Equivalent Input Noise

• Actual measurements: -128 dB EIN (IHF-A) with +60 dB/150 input

Display

• LCD with backlight (128×64 resolution)

Power Supply

• ZOOM AD-19 AC adapter (DC12 V/2 A)

Power Consumption

• 17W maximum

Manufacturer:Zoom
Model:L12
SKU:I472738-N-1-WHXB
UPC: 884354018054
