Big Mixer Energy The LiveTrak L6max 12-Channel Mixer and Recorder
The LiveTrak L6max is packed with all the features youd expect from a full-size mixer, plus a multi-track recorder. Compact, battery powered, and versatile, its ready to be the centerpiece of your live show, rehearsal, or podcast.
- 12 channels with 4 combo inputs (2 with Hi-Z) and 8 line inputs
- Two headphone outputs with customizable Sub-Out mix
- -20 dB PAD switches on channels 58 for loud sources
- High-contrast OLED display for easy navigation
- AI Noise Reduction for cleaner recordings
- 32-bit float recording with dual-AD converters on channels 14
- 3-band EQ on every channel
- Onboard effects: Reverb, Delay, and Echo with TAP tempo
- Advanced master compressor for punch and saturation
- USB audio interface: 32-bit float 12-in / 4-out, with DAW control surface mode
- Pro-level mixer functions including AUX sends, scene memory, sound pads, and MIDI I/O
- Multiple power options: AA batteries, USB bus power, or mobile battery pack
- Eurorack mountable with optional ERL-6 rack ears
Powerful Multi-Tracking
14 Tracks of Recording
Capture up to 12 individual tracks plus a stereo mix directly to SD cards up to 2TB. Projects can be saved and recalled for mixing anytime.
Unlimited Overdubbing
Mix and bounce tracks to the dedicated bounce track, freeing up channels to keep adding layers. Undo and retry bounces as needed. All files are saved to SD for future mixing.
Pro-Level Mixer Functions
Flexible Routing with AUX Sends
Two AUX sends with pre/post-fader options for FX loops and monitor feeds.
Scene Memory
Store up to four mixes and recall them anytime with a single button.
Sound Pads with MIDI Sync
Trigger jingles, sound effects, or samples instantly. Sound pads sync to MIDI clock for live electronic performances.
MIDI I/O and USB MIDI
Connect external synths and grooveboxes or integrate with MIDI apps on computer and mobile devices.
Additional Features
- Customize pads, effects, and MIDI assignments with the free L6 Editor app
- Stay mobile with multiple powering options including batteries and USB
- Designed for Eurorack integration with optional hardware
SPECIFICATIONS
Inputs
- MIC/LINE (mono): 4
- LINE (stereo): 4
- AUX SEND (mono): 2
- MASTER (stereo): 1
- MONITOR (stereo): 1
Outputs
- SUB-OUT (stereo): 1
- Connectors: 4 XLR/TRS combo jacks (XLR: 2 HOT, TRS: TIP HOT)
- Input Gain: Adjustment unnecessary (dual A/D converter circuits used)
- Input Impedance: XLR: 3.8 k or more, TRS: 18 k or more (Hi-Z off), 1 M or more (Hi-Z on)
- Maximum Input Level: XLR: +4 dBu, TRS: +24 dBu
- Phantom Power: +48 V (channel total 20 mA or less)
LINE Inputs
- Connectors: 8 TS phone jacks
- Input Impedance: 30 k or more
- Maximum Input Level: +4 dBu (PAD 0 dB), +24 dBu (PAD -20 dB)
AUX SEND
- Connectors: 2 TRS phone jacks (impedance balanced)
- Maximum Output Level: +9.5 dBu
- Output Impedance: 147
MASTER
- Connectors: 2 TRS phone jacks (balanced)
- Maximum Output Level: +15 dBu
- Output Impedance: 147
MONITOR / SUB-OUT
- Connector: TRS phone jack
- Maximum Output Level: 50 mW + 50 mW (63 load)
- Output Impedance: 14.7
Buses
- MASTER: 1
- SUB-MIX: 1
- AUX SEND: 2
The Power of a Studio. The Freedom of a Compact Mixer.
Manufacturer:Zoom
Model:L6 MAX
SKU:I849645-N-2-WHXX
EAN: 4515260030033
