Zoom M4 MicTrak Four-Track Handheld Microphone Recorder

Elevate Your Content with the Zoom M4 MicTrak Four-Track Handheld Microphone Recorder

The M4 MicTrak is the first portable recorder equipped with 32-bit float recording and built-in timecode generator, giving filmmakers and musicians everything they need to capture outstanding audio. When youre on-set you cant afford to come away with clipped or faint audio. The M4 records in 32- bit float, allowing you to capture perfect audio in any situation without the need to set gain.

• (2) XLR inputs for dialogue, while using the X/Y mics to record ambience
• Onboard X/Y mics with two additional external microphones to give your videos studio-quality sound in any environment
• Color LCD with a real-time waveform display
• Unique shock mounted X/Y mics and glossy finish significantly reduces handling noise, ensuring clean, clear audio, every time
• Built-in timecode generator has professional grade .2 ppm accuracy
• Monitor your recording using the built-in headphone output
• ‘Normalize’ function to automatically raise or lower the volume of your recording to the optimal level without compressing the audio
• ‘Prerecord’ function captures and saves six seconds of audio before you hit ‘record’
• Can be used as a 32-bit float, 4-in/2-out audio interface

SPECIFICATIONS

• Built-In Mic (Stereo): 1
• MIC/LINE (Mono): 2
• MIC/LINE In: 1
• LINE Out: 1
• PHONE Out: 1
• Built-In Speaker (Mono): 1
• Built-In Mic: 90 XY stereo format
• Directionality: Unidirectional
• Sensitivity: -42 dB/1 Pa at 1 kHz
• Maximum Sound Pressure Input: 135 dB SPL
• MIC/LINE (Mono):
• Connector: XLR/TRS combo jacks x 2 (XLR: 2 HOT, TRS: TIP HOT)
• Input Gain: Adjustment unnecessary (dual A/D converter circuit used)
• Input Impedance: MIC: 3 k or more, LINE: 3 k or more
• Maximum Input Level: MIC: +4 dBu
• LINE: +24 dBu
• Phantom Power: +24/+48 V
• LINE In (Supports Plug-In Power)
• Connector: Stereo mini jack x 1
• Input Gain: Adjustment unnecessary (dual A/D converter circuit user)
• Input Impedance: 2 k or more
• LINE Out:
• Connector: Stereo mini jack x 1
• Maximum Output Level: +1 dBu
• Output Impedance: 110 or less
• PHONE Out:
• Connector: Stereo mini jack
• Maximum Output Level: 20 mW + 20 mW (into 32 load)
• Output Impedance: 15 or less
• Built-In Speaker: 500 mW 8 mono speaker
• Maximum Simultaneous Recording Tracks: 4
• Maximum Simultaneous Playback Tracks: 4
• Display: 1.54-inch full-color LCD (240 x 240)
• USB Connector: USB Type-C
• USB Mic: USB 2.0 high speed, 48 kHz, 24-bit/32-bit float, 4-in/2-out
• File Transfer: USB 2.0 high speed
• Timecode:
• Connector: 3.5 mm stereo mini (TIP: input, RING output)
• Modes: Off, internal, external
• Frame Rate: 23.976 ND, 24 ND, 25 ND, 29.97 ND, 29.97 D, 30 ND, 30 D
• Precision: + or – .2 ppm
• Allowed Input Level: .2 – 5.0 Vpp
• Input Impedance: 4.6 k
• Output Impedance: 50 or less
• Remote: Dedicated remote control (ZOOM RC2, RC4, RCH-5, or RCH-6)
• Power: (4) AA batteries (alkaline, NiMH, or lithium)
• Adaptor: Yes (ZOOM AD-17): DC 5 V/1 A
• Stand: Not Included

Manufacturer:Zoom
Model:M4
SKU:I727852-N-0-WHXX
UPC: 884354027711
